Results 1 - 10 of 16 - Flusarc 36 - End of Life Instructions. Specification for Ring Main Units up to 36kV. Flusarc 36 Installation and comissioning. Schneider RM6 - MV Medium Voltage Compact - May 18, 2015 MV Medium Voltage Compact Switchboard (Ring Main Unit With 20 local production units around the world, Schneider Electric offer products.

RM6 switchgear proven design delivers several promises:. Enhanced personnel safety: - internal arc withstand in conformity with IEC 62271-200 - visible earthing contacts - 3 position switchgear for natural interlocking - dependable position indicating devices. Insensitive to the environment: - stainless steel sealed tank - disconnectable, sealed, metalized fuse chambers. Approved quality: - conforms to national and international standards - design and production are certified to ISO 9000 (version 2008) - field experience with over 1,800,000 functional units installed world-wide. Environmental approach - end-of-life gas recovery possible - ISO 14001 approved production site. Ease of installation: - front cable connections at the same height - easily fixed to the floor with 4 bolts.

Is economical: - from 1 to 5 functional units, integrated within the same metal enclosure for which insulation and breaking take place in SF6 gas - lifetime of30 years. Maintenance-free live parts: - in conformity with IEC 62271-1, sealed-for-life pressure system. The RM6 range offers 200 A and 630 A circuit breakers to protect both transformers and lines. They are associated with autonomous protection relays (VIP4x series) that are self-powered via current sensors or with auxiliary supply protection relays (Sepam 10 series).

A complete range, enabling you to equip Operating a distribution network sometimes requires switching points in addition MV network points and enhance '° 'ne HV/MV substations, in order to limit the effect of a fault on the network. Electrical power dependability. The RM6 offers a choice of solutions to make 2,3 or 4 directional ■ with line protection by 630 A circuit breakers ■ with network switching by switch-disconnectors ■ with integrated power supply telecontrol devices. HV/MV substation HV/MV substation. Range advantages Choosing RM6 offers you the experience The choice for your peace mind of a world leader in the field TU „„„ u „ c The new RM6 generation benefits from the accumulated experience acquired from Of Ring Mam Units. Tne -i rjOO.OOO functional units that equip electrical networks in more than 50 countries in Africa, America, Asia, Europe and Australasia. With 20 local production units around the world, Schneider Electric offer products can be made available to you in the shortest possible time.

Ring Main Unit, long experience 1983: marketing launch of the first RM6 compact with integrated. Range advantages Compact and scalable, the RM6 range covers all of your requirements RM6 Medium Voltage switchgear cubicles are perfectly suited for very simple ■ Choice of 'all In one' units integrated in a single metal enclosure ■ Cubicles insensitive to climatic conditions ■ Quick installation through floor fixing with four bolts and front cable connection. Just as compact and insensitive to climatic conditions the extensible RM6 is modular to suit your requirements. The addition of functional unit modules, allows you to build the Medium Voltage switchboard suited to your requirements.

The Schneider Electric's recycling procedure The Schneider Electric's recycling procedure forSF6 based products is subject to rigorous management, and allows each device to be traced through to its final destruction Schneider Electric is committed to a long term environmental approach. As part of this, the RM6 range has been designed to be environmentally friendly, notably in terms of the product's recycleability. The materials used, both conductors and insulators, are identified and easily At the end of its life, RM6can be processed, recycled and its materials recovered in conformity with the. Quality - Standards RM6 is designed in accordance with the following standards: General operation conditions for indoor switchgears IEC 62271-1 (common specifications for high voltage switchgear and controlgear) ■ Ambient temperature: class -25°C indoor □ lower than or equal to 40°C without derating □ lower than or equal to 35°C on 24 hours average without derating □ greater than or equal to -25°C. □ lower than or equal to 1000 m □ above 1000 m, and up to 2000 m with directed field connectors □ greater than 2000 m: please consult us for specific precaution.

IEC 62271-200 (A.C. Metal enclosed switchgear. RM6 switchgear comprises 1 to 4 integrated, low dimension functional units. This self-contained, totally insulated unit comprises: ■ a stainless steel, gas-tight metal enclosure, sealed for life, which groups together the live parts, switch-disconnector, earthing switch, fuse switch or the circuit breaker ■ one to four cable compartments with interfaces for connection to the network ■ an electrical operating mechanism cabinet ■ a fuse chamber compartment for fused switch-disconnectors or fuse switches. The performance characteristics obtained by the RM6 meet the definition of a 'sealed pressure.

Switch-disconnectors and circuit breakers have similar architecture: ■ a moving contact assembly with 3 stable positions (closed, open and earthed) moves vertically (see sketch). Its design makes simultaneous closing of the switch or circuit breaker and the earthing switch impossible. ■ the earthing switch has a short-circuit making capacity, as required ■ the RM6 combines both the isolating and interrupting function. ■ the earth collector has the correct dimensions for the network. ■ access to the cable compartment can be interlocked with the earthing switch and/ or the switch or circuit breaker. Operating safety Cable insulation test In order to test cable insulation or look for faults, it is possible to injecta direct current of up to 42 kVdc for 15 minutes through the cables via the RM6, without disconnecting the connecting devices. The earthing switch is closed and the moving earthing connection is opened in order to inject the voltage via the 'earthing covers'.

This system, a built-in feature ofthe RM6, requires the use of injection fingers (supplied asan option). Voltage indicator lamps A device (supplied as an option) on all functional units makes it possible to check the presence. RM6 Marine: benefits of the MV loop adapted to the boat The RM6 has the DNV type approval certificate for Marine applications. A MV loop configuration offers significant advantages: ■ main MV switchboard smaller (only two cells to feed a MV loop) ■ length of MV cables reduced (shortening average ratio 30% for the configuration) ■ the maintainability and availability of the network are also improved. ■ a failed cable section on the MV loop can be disconnected ■ an automatic reconfiguration of the MV loop after a fault detection ■ If RM6 is equipped with special 'filter' LRU (internal, arc Reduction. All Schneider Electric - Electrical Distribution catalogues and technical brochures.
